IBR swing check valve

PULSE

Specialized valves dispatch

Swing Check Valve

  • IBR Certified Globe Valve
  • Bypass arrangement to reduce pressure as well as operating torque
    • SIZE

    (16") 400 MM

    PRESSURE RATING

    Class 300

    TESTING STD.

    API 598

    VALVE Series

    IPC Globe Valve - 813

    Technical Specifications

    CONSTRUCTION

    Bolted Bonnet

    DESIGN STD

    BS 1873 / ASME B16.34

    End Connection

    ASME B 16.5, FERF

    Face to Face

    ASME B 16.10

    Trim No.

    Trim 8

    Operation

    Electric Actuator with Gear Box

    Flow Direction

    Uni-Directional

    Special

    BYPASS GLOBE VALVE with ELECTRICAL ACTUATOR

    Body MOC

    ASTM A216 Gr. WCB

    Plug MOC

    ASTM A216 Gr. WCB + 13%Cr

    Seat MOC

    ASTM A156 Gr.70 + ST6

    Stem MOC

    ASTM A276 TP 410

    Power Supply

    415 V, 50Hz, 3 phase

    Function (Duty)

    ON-OFF

    Power Supply
    Fail Position

    Fail lock (Stay put)

    Paint

    Heat Resistant Aluminim

    DOWNLOAD
