IPC Valves FAQ

IPC is certified for –

• ISO 9001
• ISO 29001
• ISO 18001
• CRISIL
• ATEX
• CE
• API-6D-1691 & API-600-261
• PED
• TUV
• APQ & more

Gate Valves
Design standards – API 600 / BS 1414 / API 602 / ASME B16.34
Testing standards – API 598 / BS 12266 PART 1 & 2
Ends Connection standards – ASME B16.5 / ASME 16.25
End to End standard – ASME B16.10

Globe Valves
Design standards – BS 1873 / ASME B16.34 /API 602/ API
Testing standards – API 598 / BS 12266 PART 1 & 2
Ends Connection standards – ASME B16.5 / ASME 16.25
End to End standard – ASME B16.10

Check Valves
Design standards – API 6D / API 594 / BS 1868 / ASME B16.34
Testing standards – API 598 / BS 12266 PART 1 & 2 / API 6D
Ends Connection standards – ASME B16.5 / ASME 16.25
End to End standard – ASME B16.10

This totally depends on the type of valve and quantity, if valve is off-the-shelf Valve which is in the stock, the delivery can be immediately executed. However, in case of customized requirements delivery schedule changes same is intimated to party in the enquiry stage itself.

Health Check-up and servicing of valve totally depends on the type of valve, frequency of use and how critical application is. But in a normal scenario valve should undergo a check-up at least once in 2 – 3 years and for critical applications Valve should checked at least once in a year.
(Note: these are standard guidelines; requirement may change in case of specific situation)
