PULSE
Specialized valves dispatch
MOTORIZED GATE VALVE
Actuator Make
ROTORK Electric Actuator With Integral Starter
Special Testing
100% Radiography
As Per ASME B16.34
SIZE
400 MM (NPS - 16")
TRIM
TRIM 5
PRESSURE RATING
#900
TESTING STD.
API 598
Technical Specifications
VALVE MAKE & TYPE
IPC - GATE VALVE
Design Std.
API 600, ASME B 16.34
End Connection
RTJ Flanged ends to ASME B 16.5
Construction
OS & Y, Pressure Seal Bonnet
Operating Temp
Max 425° C & Min -29° C
Body MOC
ASTM A 216 Gr. WCB
Wedge MOC
ASTM A 216 Gr. WCB + STELLITE-6
Body Seat
ASTM A516 Gr. 70 + STELLITE-6
Operating Pressure
158 Kg/cm²
Face to Face
ASME B 16.10
Leakage Class
Class - V
Flow Direction
BI-Directional
