PULSE
Specialized valves dispatch
MOTORIZED GATE VALVE
Actuator Make
ROTORK make Electrical Actuator
Special Testing
100% Radiography As Per ASME B 16.34 Critical
SIZE
100 MM
TRIM
TRIM 5
PRESSURE RATING
#1500
TESTING STD.
BS 12266-1
Technical Specifications
VALVE MAKE
IPC
Design Std.
BS 1873
End Connection
BUTT weld ends to ASME B 16.25
Construction
OS & Y, Pressure Seal Bonnet
Operating Temp
Max 425° C
Body MOC
ASTM A 216 Gr. WCB
Plug MOC
ASTM A 216 Gr. WCB + STELLITE-6
Body Seat
Carbon Steal + STELLITE-6
Operating Pressure
255 Bar
Face to Face
AS PER ASME B 16.10
Leakage Class
ANSI Class V Shut Off
Flow Direction
Uni-Direction
Coating And Pianting
Heat Resistant AI. Paint
Type
Globe Valve, IBR
