PULSE
Specialized valves dispatch
ON-OFF Pneumatic Actuated Piston Valves
SIZE
1.5" (40NB)
CONSTRUCTION
Bolted Bonnet
PRESSURE RATING
#150
TESTING STD.
API 59
Technical Specifications
VALVE TYPE
Piston Valve
Valve Paint
Standard
Design Std
ASME B16.34
Face to Face
ASME B16.10
End Connection
ASME B 16.5, FERF
Operation
Diaphram type Pneumatic Spring return Actuator with reverse Acting
End Connection STD
ASME B16.5 ferf
Solenoid Valve
3/2 Way Intrinsic Safe & Weather proof IP 67
Valve Body MOC
ASTM A216 Gr. WCB
Valve Piston MOC
SS316
Valve Seat MOC
CFT
Limit Switch Box
Two P & F Sensors Weather proof IP67
Air Supply
4 Kg/cm2
Function (Duty)
ON-OFF
Air Fail Position
Fail close
Flow Direction
UNI-Directional
