ipc valves

PULSE

Specialized valves dispatch

Swing Check Valve

SIZE

80 mm & 150 mm

TYPE

SWING CHECK VALVE

PRESSURE RATING

#600

Certification

IBR, EN10204 Type 3.1

Technical Specifications

Valve Make & Type

IPC

Flow Direction

UNI-DIRECTION

Body Seat

Stellited

Face to Face

API 6D

End Connections

Butt Weld Ends as per ASME B 16.25

Testing Std.

API 6D

Operating Temp

Max 425 °C & Min -29 °C

Leakage Class

ISO 5208 Rate G

Body MOC

ASTM A216 Gr. WCB

Coating & Paintings

HR Alluminium Paint

BODY SEAT

Stellited

End Connection

Ends Flanged to ASME B 16.5 RF Serreted Finish 125-250 AARH
