PULSE
Specialized valves dispatch
MANNUAL GATE VALVE
SIZE
80mm & 100 mm
CERTIFICATION
IBR, EN10204 Type 3.1
PRESSURE RATING
#600
DESIGN STD
API 600
Technical Specifications
Valve Make & Series
IPC
Type
GATE VALVE
Construction
OS & Y, Pressure Seal Bonnet
Face to Face
ANSI B16.10
End Connection
Butt Weld Ends as per ASME B 16.25
Testing Std.
API 598
Operating Temp
MAX 425 °C & MIN -29 °C
Leakage Class
API 598
Flow Direction
BI-Directional
Trim
Trim 5
Body MOC
ASTM A216 Gr. WCB
Body Seat
Stellited
Coating & Paintings
HR Alluminium Paint
Operating Pressure
104 Kg/cm2 Max
Wedge MOC
ASTM A216 Gr. WCB + ST-6
